311M Master? Belt Scale Weigh Frame

$0.00

The 311M belt scale weigh frame is often used in dosing belts that can regulate the capacity of a bulk flow using the measured value and a controlled belt speed.

Download product PDF
Categories: , , ,

Features

  • Semi-modular weigh frame design
  • Weigh frame without moving parts
  • Fits standard conveyors
  • Mounts with four bolts
  • Requires weigh frame cutting for proper fit
  • Minimum modifications to conveyor required

Specifications

Conveyor Width:
18 in in to 36 in (457 mm to 914 mm)

Capacity:
1,500 tons per hour

Belt Speed:
Maximum 400 feet per minute (2 m/s)

Inclination:
Maximum 12 degrees

Material:
Powder coated mild steel

Accuracy System:
1%

Load Cell:
RL1250: 50 kg, 100 kg, 250 kg

Warranty:
One-year limited warranty

Options

  • Galvanized or stainless construction
  • Custom widths available
  • Custom lifting weights available on request
