563FSAS Single Ended Beam Load Cell
$0.00
- Material: Stainless Steel
- Rated Capacities: 2.5klb
- Full Scale Output: 0.4mV/V ± 0.25%
- Safe Overload: 200% of full scale
- Breaking Overload: 500% of full scale
- IP Rating: IP66
- CE, RoHS and Ex certified
Download product PDF
Specifications
| Rated Capacity |
2.5klb |
| Full Scale Output |
0.4mV/V ± 0.25% |
| Zero Balance |
± 0.02mV/V |
| Non-linearity |
< ±0.017% |
| Repeatability |
< ±0.017% |
| Hysteresis Error |
< ±0.017% |
| Creep in 30 minutes |
< ±0.023% |
| Input Resistance |
1100Ω ± 50Ω |
| Output Resistance |
1000Ω ± 10Ω |
| Recommended Excitation |
10V (15V Maximum) |
| Insulation Resistance |
> 2GΩ (50V DC) |
| Compensated Temperature Range |
–10°C to 50°C/14°F to 122°F |
| Safe Overload |
200% of full scale |
| Breaking Overload |
500% of full scale |
| Seal Type |
Environmentally sealed |
| IP Rating |
IP66 |
