Specifications
Power Requirements: 90 to 264 VAC (50/60 Hz)
Enclosure Type: Stainless Steel
Weight: 16.2 lb / 7.3 kg (includes gimbal)
Operating Temperature: 14 to 104 ?F (-10 to +40 ?C)
Operating Humidity: 90% non-condensing (maximum)
Display Size: 5.25 in W x 4.0 in H / 133 mm W x 102 mm H
Display Resolution: 640 x 480 pixel matrix color backlit LCD
Transducer Excitation: 10.85 VDC
Load Cell Cable Length: 1260 ft maximum with sense lines, 30 ft maximum without sense lines
Division Value: 1, 2, or 5 x 10, 1, 0.1, 0.01, 0.001 and 0.0001 commercial 0 to 99, non-commercial
Signal Input Range: 1.0 mV min. to 33 mV max. (with dead load boost)
Number of Load Cells: Up to 14 per SIB / 48 – 350 ohm load cells total
Sensitivity (Non-Commercial): 0.15 uV/e
Sensitivity (Canada): 0.3 uV/e (Class III/IIIHD)
Sensitivity (OIML): 10,000 (Class III), 1000 (Class III)
Internal Resolution: >100,000 counts
Tare Capacity: Six digits (999,999)
Sample Rate: 1 to 200 samples per second, selectable
Auto Zero Range: 0.5 or 1 through 9 divisions
Weighing Units: Tons, pounds, tonnes (metric tons), kilograms, and custom
Keypad: Membrane type with 52 color-coded keys and touch screen display with multiple programmable soft keys
Sound: Configurable audio beep
Standard I/O: 2 each bi-directional RS-232 port, 1 each bi-directional RS-232/20mA port ,1 each bi-directional RS-232/RS485 port, 4 each isolated inputs and 4 each isolated outputs ports, 1 each 10/100 Base-T Ethernet port (TCP/IP or EIP), 2 each USB A host port, 1 each USB B device port
NTEP Approval: 08-046
OIML: R76/1992-DK1-08.03
Enclosure IP Rating: IP66
