ASTM Range 1 kg Precision Laboratory Metric Sets

$0.00

ASTM precision laboratory metric sets with a one kilogram range have a stainless steel polished finish and are designed to meet ASTM E617-13 specifications.

Download product PDF
Categories: ,

Features

  • Stainless steel polished finish
  • Designed to meet ASTM E617-13 specifications
  • ASTM Class 0 weight sets and individual weights are not individually marked with their weight value or individually serialized per ASTM E617-13
  • Nominal value marked on weights
  • Serial numbers applied to case (weights may be marked with symbol)
  • Density 7.95g/cm3

Specifications

1 kg – 1 mg 1 kg – 100 mg 1 kg – 1 g 1 kg – 1 g* 1 kg – 100 g
1 – 1kg 1 – 1 kg 1 – 1 kg 1 – 1 kg 1 – 1 kg
1 – 500 g 1 – 500 g 1 – 500 g 1 – 500 g 1 – 500 g
1 – 300 g 1 – 300 g 1 – 300 g 2 – 200 g 1 – 300 g
1 – 200 g 1 – 200 g 1 – 200 g 1 – 100 g 1 – 200 g
1 – 100 g 1 – 100 g 1 – 100 g 1 – 50 g 1 – 100 g
1 – 50 g 1 – 50 g 1 – 50 g 2 – 20 g
1 – 30 g 1 – 30 g 1 – 30 g 1 – 10 g
1 – 20 g 1 – 20 g 1 – 20 g 1 – 5 g
1 – 10 g 1 – 10 g 1 – 10 g 2 – 2 g
1 – 5 g 1 – 5 g 1 – 5 g 1 – 1 g
1 – 3 g 1 – 3 g 1 – 3 g
1 – 2 g 1 – 2 g 1 – 2 g
1 – 1 g 1 – 1 g 1 – 1 g
1 – 500 mg 1 – 500 mg
1 – 300 mg 1 – 300 mg
1 – 200 mg 1 – 200 mg
1 – 100 mg 1 – 100 mg
1 – 50 mg
1 – 30 mg
1 – 20 mg
1 – 10 mg
1 – 5 mg
1 – 3 mg
1 – 2 mg
1 – 1 mg
Piece Count
25 17 13 13 5
Total Weight
2.222221 kg 2.2221 kg 2.221 kg 2.11 kg 2.1 kg
Part # Part # Part # Part # Part #
45919-Class 0 45920-Class 0 45921-Class 0 – 45922-Class 0
12473-Class 1 45972-Class 1 12476-Class 1 11889-Class 1 45976-Class 1
11922-Class 2 45973-Class 2 11925-Class 2 12149-Class 2 45977-Class 2
12070-Class 3 45974-Class 3 12073-Class 3 12288-Class 3 45978-Class 3
12216-Class 4 45975-Class 4 12219-Class 4 12391-Class 4 45979-Class 4

Options

36092 Form,Statement of Accuracy
11714 Weight Glove,Cloth White
11711 Weight,Tweezers 3.54x.46 Delrin
Tweezers,Straight Tip 140 mm, Tips made of PA12 Plastic and Carbon Fiber
25836 Serial Number
11755 Cover,Leaf Weight
50035 Weight Forceps, 4-3/4 Plastic, 200g to 500g
11747 Weight,Lift 3/8×7/8×5.89 Handle Plexiglass, 200 g to 3 kg
50000 Tong ASSY,24cmx7.5cm W/ Surgical Tubing On Ends

Models

45919 Weight Set,1kg-1mg ASTM Class 0 SST (5321), Calibration Certificate Included
45920 Weight Set,1kg-100mg ASTM Class 0 SST (5321), Calibratin Certificate Included
45921 Weight Set,1kg-1g ASTM Class 0 SST (5321), Calibration Certificate included
45922 Weight Set,1kg-100g ASTM Class 0 SST (5321), Calibration Certificate Included
