Specifications
Power-AC:
Line voltages:
115/230 VAC
Frequency:
50/60 Hz
Power Consumption:
1.5 A at 115 VAC (8 W),
0.75 A at 230 VAC (8 W)
Measurement Rate:
960, 480, 240, 120, 60, 30, 15, 7.5 per second
System Linearity:
?0.01% full scale
Digital I/O:
Four channels on CPU board
Circuit Protection:
RFI, EMI, ESD protection
Display:
Large 0.8 in, 14-segment, six-digit high-intensity red
LED display
Status Annunciators:
Designators for %, kg, gm, lb, oz, center of zero, G/B, N, T, PT, neg, motion
Operating Temperature:
Legal: 14? F to 104? F (-10? C to 40? C)
Rating/Material:
IP69K, stainless steel
Display Resolution:
100,000 graduations maximum
Load Cell:
IP69K, stainless steel, hermetically sealed
Warranty:
Three-year limited warranty
Approvals:
Indicator:
NTEP CC 08-092, Class III/IIIL 10,000 d
Measurement Canada AM-5710, Class III 10,000 d
OIML R76/2006-GBI-10.02
TC GB-1385
TAC UK2900
UL and CUL listed
CE marked
Scale:
NTEP CC 95-072, Class III 5,000 d
Measurement Canada AM-5082, Class III 5,000 d
NSF
Options
196407 Ind OPT,Ethernet Interface CW90, CW90X List price: $400.00
108671 Ind Opt,Wireless LAN Card WiFi 802.11 A/B for CW90, CW90X, 720i, 820i, iQube2 List price: $570.00
93245 Ind Opt,USB Port for PC Connection, includes 1 meter Type A to mini-B cable List price: $175.00
95357 Cable,USB Type A To USB Mini-B 1 Meter Long List price: $10.00
171968 Cable,RS-232 5-Wire DB-9F to stripped and tinned leads List price: $35.00
96736 Ind Opt,Fiber-Optic Rx/Tx CW90, CW90X, 820i Internal Mount With Bus Power List price: $250.00
78026 Cable,Plastic Optical 100 ft. includes polishing kit List price: $140.00
80892 Cutter, Fiber Optic Disposable, .750 and 1.0mm single and duplex jacket Industrial Fiber Optics #IF-FC2 List price: $9.00
117358 CD,Software Pkg WVault Weighvault for CW90 Version List price: $250.00
