Wireless operation
Operates up to 10 hours on a single charge
Datalogic’s patented ‘Green Spot’ technology for good-read feedback
Polycarbonate molded with rubber
Multi-point operation allows for multiple scanner communications to a single base station
Linear Imager
Light Source:
VLD between 630 to 380 nm
Decode Capabilities:
Codabar, Codablock F, Code 11, Code 128, Code 32, Code 39, Code 39 CIP, Code 39 Full ASCII, Code 4, Code 5, Code 93, Datalogic 2 of 5, GS1 DataBar, IATA, Industrial 2 of 5, Interleaved 2 of 5, ISBN, MSI, Plessey, Standard 2 of 5, UPC/EAN supplementals
Dimensions:
Scanner: 8.4 × 4.5 × 2.8 in
(212 × 109 × 71 mm)
Base station: 10.5 × 3.5 × 2.5 in
(266.7 × 88.9 × 63.5 mm)
(width is 4.2 in/106.68 mm including mounting knobs)
Display:
LCD: 6 lines × 16 characters
Base Station:
US: 110 V±10%, 60 Hz
Weight:
Scanner: 14.2 oz (405 g)
Base station: 16 oz (454 g)
Communications:
Host: RS-232 with DB9 S, P/S and 12 ft cable.
KBW (keyboard wedge) with P/S and 6 M Din, coiled cable 12 ft
USB, 12 ft coiled cable
Frequency Range:
(varies by country)
915 mHz
Temperature Range:
Operating: -4 °F to 122 °F (-20 °C to 50 °C)
Storage: -40 °F to 158 °F (-40 °C to 70 °C)
Humidity:
0 to 90% non-condensing
IP Rating:
Scanner: IP65
Base station: IP64
Drop Resistance:
2 m
Battery Type:
Li-Ion 2150 mAh
Electrical:
Complies to C-CSA-US
(60950 Canada and USA)
Warranty:
Three-year limited
