Specifications
Internal Resolution:
1/1,000,000
Weight Display Resolution:
1/5,000 NTEP, other selections capacity dependent
Display:
LED
Weight: five-digit
Unit weight: five-digit
Quantity: seven-digit
Tare: five-digit
Power Source Consumption:
AC: 115, 60 Hz
Optional battery: 6 V, 5.0 Ah
Printer Compatibility:
Zebra GK-420D
Zebra GK-420T
Epson TM-U220 tape
STAR SP512 tape
Epson TM-U295 ticket
Zero Adjust Range:
?127% full scale
Input Sensitivity:
0.4 to 4 mV/V
Load Cell Excitation:
5 VDC
Number of Scale Channels:
One remote scale, one 350 ? load cell
Memory Items:
100 items
Load Cell Input Connector:
Amphenol 14-Pin
Computer Interface:
RS-232 DB-9M connection
Battery Operation:
24 hours of continuous usage
Charge Time:
8-10 hours
Operating Temperature:
14? F to 104? F (-10? C to 40? C)
Dimensions:
Overall (W x D x H): 14 x 13.75 x 4.5 in (354 x 349 x 115 mm)
Estimated Shipping Weight:
15 lb (7 kg)
Warranty:
Two-year limited warranty
Approvals:
NTEP CC 07-015 (10 lb – 100 lb) Class III for
weigh mode only
10 lb to 100 lb-scales only
Options
88933 Battery,DC-788 6V, 5.0AH Sealed Lead-acid
73386 Tray, Sample Plastic, Anti-Static DC-180, DC-150, DC-688, DC-788, ST-10
32375 CONN,Plug 14-Pin Male DIGI connector
35319 Cable,4 Conductor 20ft Used On Roughdeck W/DIGI (Not Designed to Work w/Y-Cable)
91685 Manual,Operating DC-788
70056 Cable,RS232 DB9M To DB9F Straight Cable
72440 Cable,RS232 Straight 25 Pin D SUB Male to 9 Pin D SUB Female, Pinout: 2 to 2, 3 to 3, 5 to 7 G, RTS to DSR, DSR to DTR
66535 Cable,DB9F to DB9F Null Modem Serial Cable 6 Foot
91214 Power Supply,DC-788 120V 60HZ, 18W, 9VDC, 600mA
