Specifications
Full Scale Output:
1 mV/V
Output Resistance:
1,000 (± 10) ohm
Input Resistance:
1,180 (± 50) ohm
Material/Finish:
Aluminum
Temperature:
Operating range
0° F to 150° F (-18° C to 65° C)
Seal Type:
Environmentally sealed, IP65
Safe Overload:
150% full scale
Rated Excitation:
5-10 VDC
Combined Error:
0.060% full scale
Insulation Resistance:
5,000 megohms
Cable Length:
1.5 m (4.9 ft)
Cable Color Code:
Green +Excitation
Black –Excitation
White +Signal
Red –Signal
Yellow Shield
Warranty:
One-year limited warranty
