Specifications
Full Scale Output:
2.0 mV/V
Matched outputs via mV/V/ohm calibration
Output Resistance:
1,000 (± 2) ohm
Input Resistance:
1,100 (± 50) ohm
Material/Finish:
Stainless steel
Temperature:
Operating range
0° F to 150° F (-18° C to 65° C)
Seal Type:
Hermetically sealed, IP69K
Safe Overload:
200% full scale
Rated Excitation:
5-10 VDC (15 V maximum)
Nonlinearity:
0 to -0.03% full scale
Hysteresis:
0 to +0.05% full scale
Combined Error:
± 0.03%
Insulation Resistance:
10,000 megohms
Cable Length:
20 ft (6.1 m)
Cable Diameter:
0.196 polyurethane jacket
Cable Color Code:
Green +Excitation
Black –Excitation
White +Signal
Red –Signal
Yellow Shield
Warranty:
One-year limited warranty
Approvals:
FM
OIML
