Print Speed:
203 dpi: 2 to 10 ips
300 dpi: 2 to 8 ips
Supply Roll Capacity:
8 in (203 mm) O D on 1.5 to 3.0 in (38 mm to 76.2 mm) cores
Fanfold stock accepted from rear and bottom of printer
Bar Code Modulus:
5 mil to 55 mil “X” dimension in picket fence or ladder orientations
Media Width:
0.75 to 4.5 in (17 to 114 mm)
Media Type:
Roll fed or fan-fold materials, die-cut or continuous labels; perforated or continuous tag/ticket stock
Print Length:
0.25 to 99 in (6 to 2,475 mm)
Media Thickness:
0.0025 to .01 in (0.0635 to 0.254 mm) |
Ribbons:
Industry standard ribbon widths; 1 in (25 mm) ribbon core, 1,476 ft (450 m) in length
Bar Codes:
Code 3 of 9, UPC-A, UPC-E, Interleaved
2 of 5, Code 128, EAN-8, EAN-13, HIBC,
Codabar, Plessey, UPC 2 and 5 digit
addendums, Code 93, Postnet, UCC/EAN Code 128, Telepen, UPS MaxiCode, FIM, PDF417, USD-8, Datamatrix, QR Code, Aztec,
TLC 39, Micro PDF417, RSS
Graphics Supported:
.PCX, .BMP and .IMG files
Dimensions:
(L x H x W)
438 × 270 × 249 mm
(17.24 × 10.63 × 9.80 in)
Weight:
10.82 kg (23.85 lbs) |
Memory:
128 MB RAM
Processor:
Arm Cortex®-A7 800 MHz
Power Source:
Auto-sensing 90 to 132 or 180 to 264 VAC at 47 to 63 Hz
Operating Temperature:
40 °F to 95 °F (4 °C to 35 °C)
Warranty:
One-year limited
Printhead (original): One-year or 1 million linear inches
Printhead (replacement): 90 days
Approvals:
CE
FCC
UL
CSA certified
TUV-GS safety standards
RoHS
WEE compliant |
