Ishida Uni-3 Series

$0.00

Extraordinary Power. Exceptional Value.

With premium-class presets, fast print speed, and more labeling functions, you are getting more flexibility and more features—all for less cost than comparable price computing scales with printers.

With three models and two display types, you can easily find a Uni-3 to fit your specific application needs. Ethernet or optional wireless communication enables any Uni-3 to be added to your existing network—ensuring you have consistent control of all scales in your store.

Product management software ensures easy file maintenance as well as PLU and tare weight consistency throughout your operation. The power of the Uni-3 is at your fingertips with flexible preset buttons to represent PLUs, container tare values, label formats, images and logos.

The Uni-3 L1 model features a vibrant blue alphanumeric display with a sharp white 16-segment capability. The Uni-3 L2 model features a clear LCD display with one line alphanumeric and one line numeric. Each model offers a matching customer display.

Download product PDF
Categories: ,

Features

  • Blue alphanumeric LCD display (23 digits, 16 segments) or backlit alphanumeric LCD display (23 digits, 7 segments)
  • Dual-range weighing (0-15 lb x 0.005 lb/15-30 lb x 0.01 lb)
  • Side-load label
  • Fast printing speed (3.9 in/ 100 mm per second)
  • Meat nutrition and 2020 nutrition labeling
  • Multiple label formats
  • Powerful batch printing feature
  • Static TCP/IP Ethernet communication
  • 84 one-touch preset keys, 168 presets (assign two items/key)
  • Flash ROM for simple update of application software
  • 2 MB memory
  • Proportional tare
  • Compatible with third-party communication software, including ADC’s InterScale and Invatron’s PLUM

Specifications

Capacity (Dual Range):
0 to 15 × 0.005 lb/15 to 30 × 0.01 lb

Capacity (Single Range):
0 to 60 × 0.02 lb option

Weighing Resolution:
3,000 display divisions maximum

Display Types:
L1: LCD, blue alphanumeric (23 digits 16 seg)
L2: LCD, backlight, alphanumeric (192 × 16 DM + 23 digits 7 seg)

Display Items:
Tare: Four-digits
Weight: Five-digits
Total price: Six-digits

 Preset Keys:
84 one-touch preset keys 168 presets (assign two items/key)

Memory Capacity:
2 MB

Communications:
TCP/IP 10/100 Base T Ethernet

Platter:
14.5 × 10.5 in

Printing Speed:
3.9 in (100 mm) per second

Printing:
Direct thermal 2.2 in (56 mm)

Label Size:
Width: 1.5 to 2.5 in (38 to 64 mm)
Length: 1.2 to 6.9 in (30 to 175 mm)

 Label Roll:
Inside diameter: 1.6 in (40 mm)
Outside diameter: 3.9 in (100 mm)

Label Backing Paper:
Width: Up to 2.6 in (66 mm)

Power Supply:
AC100 to 240 V, 50/60 Hz

Power Consumption:
Stand-by: 50 W
In operation: 100 W

Classification:
NTEP CC 07-005
UL Listed

Warranty:
One-year limited

Options

165200 Retail Scale, Uni-3L1 Bench, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
165201 Retail Scale, Uni-3L1 Pole, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
173882 Retail Scale, Uni-3L1 Bench, LCD display, 60 x 0.02lbs, Integrated printer, 115VAC Ishida
173883 Retail Scale, Uni-3L1 Pole, LCD display, 60 x 0.02lbs, Integrated printer, 115VAC Ishida
165202 Retail Scale, Uni-3L2 Bench, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
165203 Retail Scale, Uni-3L2 Pole, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
173884 Retail Scale, Uni-3L2 Bench, LCD display, 60 x 0.02lbs, Integrated printer, 115VAC Ishida
173885 Retail Scale, Uni-3L2 Pole, LCD display, 60 x 0.02lbs, Integrated printer, 115VAC Ishida
219463 Retail Scale, Uni-3L2 Retail Scale, Uni-3L2 Bench, Internal Wireless option, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
219464 Retail Scale, Uni-3L1 Retail Scale, Uni-3L1 Bench, Internal Wireless option, LCD display, 0-15lbs x 0.005, 15-30lbs x 0.01 Integrated printer, 115 VAC Ishida
170541 Option,Liner Free Kit Uni-3 Ishida
47976 Retail Scale OPT,Fish Platter 9-1/2 in Deep x 13-1/2 in Wide Ishida
47977 Retail Scale OPT,Produce Platter 9-1/2 in Deep x 13-1/2 in Wide Ishida
