Mechanical Portable

$0.00

Constructed entirely of heavy-duty welded fabricated steel bases and electrostatic long-life paint coating, Cardinal?s mechanical portable scales provide portable, fast, accurate performances. These models come in your choice of platforms sizes 19 x 28 or 28 x 28 inch, and the simplified lever system offers maintenance-free, simple operation. Large 5 inch diameter heavy-duty rubolene wheels and a die-cast easy-to-read weighbeam round out the rest of the features. NTEP legal-for-trade. A variety of capacities are available to choose from.

Download product PDF
Categories: ,

Features

  • 5-in-diameter Wheels
  • Die-Cast Weigh Beam May Be Read From Either Side
  • NTEP Legal for Trade

Specifications

Platform Size (854F):?19 x 28 inch / 483 x 711 mm
Platform Size (954F):?28 x 28 inch / 711 x 711 mm
Wheels:?Large 5 in (127 mm) diameter heavy-duty rubolene
Overall Dimensions (854F):?45 H x 24 W x 35 D in / 114 H x 61 W x 89 D cm
Overall Dimensions (954F):?45 H x 33 in W x 35 D in / 114 H 84 W x 89 D cm
Shipping Weight (854F):?132 lb / 60 kg
Shipping Weight (954F):?206 lb / 93 kg
NTEP Approval:?88-106A1 (854) and 88-108A1 (954)

Models

854F100P Portable Scale, Mechanical Beam, 19? x 28?, 1,000 Lb Capacity
854F50P Portable Scale, Mechanical Beam, 19? x 28?, 500 Lb Capacity
854F50K Portable Scale, Mechanical Beam, 19? x 28?, 500 Kg Capacity
854F50PK Portable Scale, Mechanical Beam, 19? x 28?, 500 Lb / 200Kg Capacity
854F100PK Portable Scale, Mechanical Beam, 19? x 28?, 1,000 Lb / 500Kg Capacity
