Network-capable: RS-485 interface is X-bus compatible
Built-in internal calibration function: at the touch of the unique ISO TEST Key, the IS platform calibrates and adjusts itself automatically using a built-in calibration weight
High resolution: guarantees reliable weight readouts
Fast weighing results: up to 50 times/second
Stainless steel load plate: all scales come standard with stainless steel load plate
High IP rating for ideal protection
Specifications
Indicator Connectivity:
Combics CAIXS2 with option
Weighing Design:
Electro magnetic
Cable Length:
9 ft (2.75 m)
Stability:
Weight stabilizes 1.5 second
Interface:
RS-485 standard
Power Requirements:
Requires YPS02-XKR (46518) hazardous area power supply or YPS02-ZKR (46517) safe area power supply
Construction:
Stainless steel platform, die cast or galvanized base construction (model dependent)
Ingress Protection:
CCE: IP54
EDE: IP65
IGG: IP67
Warranty:
Two-year limited warranty; accessories one year
Options
155918 Interface,485 OPT A19 Combics 3 EX for IS-X base
155919 Cable,IS-X OPT M26 Combics 3 EX for IS-X base
158644 Indicator,CAIXS2-U EX Combics 2 EX-Proof Indicator, SS, FM approved, Requires Power Supply or Battery Pack Pair with Combics EX, IF EX or IS EX
155882 Barrier,Zener YD105-ZU1 Minebea, RS-232 Converter, Includes 20m open-end cable
103055 Barrier,Zener RS232-RS232 Minebea YD105-ZU2
103059 Accessory,Combics, DWI Zener Barrier, With Option Cable Up To 3,200 Feet. Requires YCC422-X Type A, RLWS 103057 3,200 Feet Connection To CIXS3, Or YCC422-X Type B, RLWS 103058 3,200 Feet Quick Disconnect
Models
Part #?155877
Product DescriptionBase,IS16EDE-HX Explosion Minebea IS Series, 16kg x 0.1g, 15.8 x 11.88in platform, Painted,Needs power supply-46518(YPS02-XKR) or 46517(YPS02-ZKR)
Part #?155878
Product DescriptionBase,IS34EDE-HX Explosion Minebea IS Series, 34kg x 0.1 g, 15.8 x 11.8in platform, Painted, Needs power supply-46518 (YPS02-XKR) or 46517(YPS02-ZKR)
Part #?155879
Product DescriptionBase,IS64EDE-SX Explosion Minebea IS Series, 64kg x 1 g, 15.8 x 11.8in platform, Painted Requires power supply – 46518 (YPS02-XKR) or 46517 (YPS02-ZKR)
Part #?155880
Product DescriptionBase,IS150IGG-HX Signum-X Minebea IS Series, 150kg x 1 g, 32 x 24in platform, Painted Requires power supply – 46518 (YPS02-XKR) or 46517 (YPS02-ZKR)
Part #?155881
Product DescriptionBase,IS300IGG-HX Signum-X Minebea IS Series, 300kg x 2g, 32 x 24in platform, Painted Requires power supply – 46518 (YPS02-XKR) or 46517 (YPS02-ZKR)
Part #?181654
Product DescriptionBase,ISXBBS-3-H Explosion Minebea IS Series, 3.1 kg x 0.01 g, 7 x 7in platform, Painted Requires power supply – 46518 (YPS02-XKR) or 46517 (YPS02-ZKR)
Part #?156371
Product DescriptionBase,IS64EDE-HX Explosion Minebea IS Series, 64kg x 0.1g, 15.8 x 11.8in platform, Painted Requires Power Supply 46518 (YPS02-XKR) or 46517 (YPS02-ZKR)
