Motor Truck Scale Electronic Conversion Kit

$0.00

A Conversion Kit that Minimizes Downtime

Full electronic performance can be achieved at a fraction of the cost of a new scale and pit. The Motor Truck Scale (MTS) electronic conversion kit is designed to transform an existing scale pit and weighbridge into a fully electronic vehicle scale. Designed for quick installation without removing the platform or reconfiguring the pit, the conversion kit can often be installed in a matter of days, minimizing downtime. This ease of installation is important when considering installations where it is not feasible to completely remove the existing scale.

Applications:

  • Updating existing mechanical motor truck scales
  • Replacing unsatisfactory electronic motor truck scales
  • Conversion of heavy-capacity scales into fully electronic vehicle scales where the existing scale cannot be removed
Download product PDF
Categories: ,

Features

Motor Truck Scale Electronic Conversion Kit

Complete Kit Includes

  • Four, six or eight Translink mounting assemblies with NTEP Certified RL75040 or RL75223 welded-seal load cells
  • One JB8SP NEMA Type 4X signal-trim junction box with individual and section trimming capability (six- and eight-mount kits) or one JB4SP NEMA Type 4X signal-trim junction box (four-mount kits)
  • One UJB3T6 DC transient protector
  • 100 ft of hostile environment EL147HE SURVIVOR® load cell cable

Standard Features

  • Capacity (per module): 25,000 to 100,000 lb
  • Cost and time efficient installation; no need to remove weighbridge
  • Converts existing scale capacities of 40,000 to 300,000 lb
  • Four, six or eight-mount kits for two, three or four section conversions
  • Translink™ heavy-capacity mounting assemblies
  • Free movement in all directions in the horizontal plane with virtually no friction
  • Completely self-centering
  • Requires no check rods
  • Compatible with VPG® Sensortronics 65040A or VPG® Revere 5223 load cells

Specifications

Rated Capacity C H* H1 H2 L L1 L2 L3 L4 L5 W W1 W2 W3 W4** W5
lb/inches
50,000 to 100,000 (RL75223) 1.50 12.93 1.00 1.00 22.50 1.50 1.75 9.50 11.75 5.88 7.75 0.91 5.25 1.25 9.25 11.75
25,000 to 40,000 (RL75040A) 1.50 9.88 1.00 1.00 18.50 1.50 1.75 7.50 11.75 5.88 7.75 0.91 5.25 1.25 9.25 11.75
50,000 to 75,000 (RL75040A) 1.50 12.82 1.00 1.00 22.50 1.50 1.75 9.50 11.75 5.88 7.75 0.91 5.25 1.25 9.25 11.75
*Custom heights available; Consult
**Custom hole spacing for existing bolt patterns is available; Consult
