12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard)
Hi-torque load train designed for use with powered rotation
Options
(Contact MSI for application consultation)
Top shackle
Rugged Remote (control for on/off, zero, tare and other functions)
Anti-heat shielding for high-temperature applications
Substitute bottom hook with shackle
Oversized top or shackle
Oversized bottom hooks
Universal direct power supply
Wi-Fi communication is available for specialty applications
RF modem install for connectivity to MSI-8000, MSI-8000HD RF, MSI-8004HD RF remote display, TranSend™ and LaserLight2 remote display
Typically 100 to 300ft, line of sight; for longer range consult factory Low headroom top adapter
Audible alarm
Custom top and bottom interfaces
Specifications
Accuracy:
10,000 to 120,000 lb: ± (0.1% +1 d) of capacity
200,000 lb: ± (0.2% +1 d) of capacityResolution:
3,000 to 5,000 d standard (Up to 10,000 d available)Enclosure:
NEMA Type 4, IP66, marine grade 356 alloy anodized cast aluminum
Lifting Eye, Shackle & Hook:
Shackle is optional and Crosby® fixed hook provided as standard
Design Overload:
200% Safe / 500% Ultimate (except where noted)
Functions:
Power: Turns unit on or off
Zero: Zeros applied load up to 100% of capacity
Tare: Tares applied load and displays weight in net
Mode F1: Programmable as test, units, net/gross, total and peak holdDisplay: 1.5″ (38 mm, 6-digit, programmable LED display, multi-color (red, orange, and green)Displayable Units:
Pounds or kilograms selectable
Power: 12 Volt rechargeable battery, 115/230 VAC battery charger included
Operating Time:
Up to 30 hours between charging with typical useTemperature Range:
Operating: 14 °F to 131 °F (-10 °C to 55 °C)Filtering: OFF, LO, HI-1 or HI-2 selectable
Radio Link:
802.15.4 at 2.4 GHz
Radio Link Effective Range:
Typically 100 to 300 ft line of sight
Warranty:
One-year limited
Options
214371
MSI-9600HT 10K FINAL ASSY TORQUE RESISTANT
214370
MSI-9600HT 30K FINAL ASSY TORQUE RESISTANT
214369
MSI-9600HT 70K FINAL ASSY TORQUE RESISTANT
214477
MSI-9600HT 100K Shear Web Final Assy Torque Resistant
214479
MSI-9600HT 200K Shear Web Final Assy.Torque Resistant
214474
MSI-9600HT 120000Lb Final Assembly. Torque Resistant
141992
Shackle Anchor 17 Ton Bolt Type, G-2130
146335
Shackle Anchor 40 Ton Bolt Type
146336
Shackle Anchor,55 Ton Bolt Type
150971
MSI-4260B Remote Disp Opt Kit, RF. Modem Will Allow For Connectivity With an MSI-8000 Remote Display
173014
MSI-Rugged Remote Control Non-CE for Products with XBEE Radios
153591
FINAL ASSY REMOTE DISPLAY AC POWER 8000HD
178004
4in LASERLIGHT2 MSI RF Includes ScaleCore RF Kit and Tilt Mounting Bracket
178006
6in LASERLIGHT2 MSI XBEE RF Includes ScaleCore RF Kit and Tilt Mount Bracket
159221
MSI CRANE CART (48.50)
176956
MSI-4260B/4260C/9600HT & 6360 WIFI Opt. Kit. WIFI Modem Will Allow For Connectivity With Scaleconnect App.
