MSI Scoreboards Wireless RF

$0.00

Download product PDF
Category:

Features

  • Compatible with: MSI-7300 Dyna-Link 2, MSI-3460 Challenger 3, MSI-4260 Port-A-Weigh, MSI-7000 and MSI-7001 TranSend™, MSI-9600HT, MSI-6360, MSI-8000HD and MSI-8004HD
  • Tilt mounting bracket
  • Integrated data repeater
  • Six high-intensity red digits (double-row discrete LED)
  • Auto Learn mode of communication protocols
  • Hold displayed weight (demand input)
  • Software selectable standstill mode for no updates while in motion
  • Durable weather-tight IP66 enclosure
  • Adjustable daylight/night intensity
  • Non-glare contrast filtered lens
  • Mirror (reverse image) feature
  • RS-232, 20 mA and RS-485 communications
  • Auto sensing 115/230 VAC power supply
  • PEMs for VESA flat-wall mount or side-mounting flange available
  • Polyethylene breather vent inhibits internal moisture buildup

Specifications

Enclosure:
NEMA Type 4, IP66Display:
Six-digit long-life LED, 4 in or 6 in

Power:
AC/DC power supply 85 to 265 VAC, 47 to 440Hz/130 to 300 VDC

 Radio Link:
Direct sequence spread spectrum at 2.4GHzRadio Link Effective Range:
Typically 100 to 300 ft, line of sight; for longer range consult factory		 Standard Antenna:
1/2 wave 2 dBi, articulatedWarranty:
One-year limited

Echo Data Output:
RS-232

Options

178004 4in LASERLIGHT2 MSI RF Includes ScaleCore RF Kit and Tilt Mounting Bracket
178006 6in LASERLIGHT2 MSI XBEE RF Includes ScaleCore RF Kit and Tilt Mount Bracket
178341 Display,LaserLight2 4-IN W/Tilt, Bracket ASSY
178342 Display,LaserLight2 6-IN W/Tilt, Bracket Assembly
139309 ANTENNA KIT LONG RANGE OMNI W/3M COAX
139310 ANTENNA KIT CORNER REFLECTOR 9DBI W/3M COAX
139311 ANTENNA KIT CORNER REFLECTOR 12dBi W/3m COAX
139313 ANTENNA KIT VEHICLE MOUNT 5DBI W/5M COAX
162178 Option Kit Remote Antenna 7000/7001 (Uses Standard Antenna)
197013 Option Kit Remote Antenna Cable TNC (Uses Standard Antenna)
178318 Bracket ASSY,Wall Mount Adjustable Tilt For 4 inch and 6 inch Laserlight2
