MVS Mount/MVS Weigh Modules

$0.00

Truck Scale Conversion Weigh Module

The MVS utilizes the center-loaded double-ended shear beam load cell design. The mount is self-centering, which eliminates the need of costly check rods. This results in a pendulum suspension effect that eliminates binding, protects the load cells from damaging side load common on truck scales and automatically returns the mount to dead center. The mount is easy to install and promises high performance and long life.

Applications:

  • Truck scale conversion
  • Heavy-capacity horizontal tanks
Download product PDF
Categories: ,

Features

MVS Mount/MVS Weigh Modules

Complete Kit Includes

  • Four to ten MVS mild steel mounts with RL75058-LP 75,000 lb NTEP Certified alloy steel environmentally sealed double-ended beam load cells.
  • One JB8SPT NEMA 4 Type signal trim junction box (JB1010 on 10 module kit)
  • 100 ft of our hostile environment EL147HE SURVIVOR® load cell cable

Standard Features

  • Capacity (per module): 10,000 to 125,000 lb
  • Mild steel construction
  • Specially hardened center link
  • Self-checking design
  • Self-centering design
  • Accommodates thermal expansion and contraction
  • Compatible with VPG® Sensortronics 65058 or VPG® Celtron CLB

Specifications

Rated Capacity A B C D E F G H I J K
lb/in
10,000 to 25,000 7.25 14.00 7.00 6.00 7.00 5.25 4.50 11.50 3.50 8.50 4.00
50,000 to 75,000 11.00 14.25 12.00 7.00 – 11.00 10.00 7.25 3.50 11.53 4.00
100,000 to 125,000 12.50 14.75 17.25 9.00 – 12.75 14.25 11.25 5.00 14.21 6.00
