Okidata 186 Turbo

The Okidata 186 Turbo Microline forms printer is rugged, reliable and built for speed.

Unfortunately this product has been DISCONTINUED. For similar products click here.
Category:

Features

  • Vertical tabs
  • Long-lasting, self-inking ribbon cartridge
  • Bit image graphics for plotting charts, graphs and drawings
  • Full ASCII character set
  • Friction and adjustable pin feed paper handling
  • Nine-pin, long-life print head
  • RS-232 interface or USB
  • Near letter-quality printing at 50 characters per second
  • Superscripts, subscripts and underlining
  • Bottom, rear or top feed

Specifications

Print Method:?
Nine-Pin (0.34 mm dia.) serial impact dot matrix

Graphics Resolution:
240 x 216 maximum

Print Speed* (CPS):
NLQ: 62; Utility: 250; High Speed Draft: 333; Super Speed Draft: 375

Feed Rate:
2.0 ips

Emulations:
IBM 2480 Epson E6C/P or OKI Microline

Interface:
USB or RS-232

Compatibility:
186/Windows XP, 2000, 98/95

Receive Buffer:
One line buffer

Paper Input:
Cut sheet, 7.2 in to 8.5 in W
(182.9 mm to 215.9 mm W)
Bottom feed with pull tractor option

Number Of Copies:
Five copies

Pin Feed:
Continuous, 9.5 in to 10.5 in wide
(241.3 mm to 266.7 mm wide)

Paper Thickness:
0.014 in (0.35 mm) maximum

Paper Path:
Bottom, rear or top

Paper Weight:
Cut sheet: 16 lb to 24 lb (7.2 kg to 10.8 kg),
Continuous: 16 lb to 20 lb (7.2 kg to 9.1 kg)

Electrical:
120 VAC: ?10%; 220/240 VAC: ?10%

Power Consumption:
Operating: 35 W
Idle: 7 W

Reliability (MTBF):
70,000 hours

Print Head Life:
200 million characters

Ribbon Type:
Black cartridge (2 million characters nominal life)

Operating Temperature:
40? F to 104? F (4? C to 40? C) at 25% to 80% relative humidity

Overall Size:
(W x D x H): 14.2 x 10.8 x 3.2 in
(360.7 x 274.3 x 81.3 mm)

Est. Ship Weight:
10 lb (4.5 kg)

Warranty:
One-year limited warranty (includes print head)

* Print speeds apply to all ?pitches (10, 12, 17.1, and 20 cpi)
** Requires optional pull tractor (part #41224)

Options

Part #20236 Product DescriptionPrinter OPT,Tractor Feed Kit 184 Turbo and 186 Microline Okidata
Part #20664 Product DescriptionCartridge,Ribbon Black Okidata 184 and 186 Printer, Magnetec 3500-S, Okidata 320 and 390
Part #21208 Product DescriptionCover,Dust 184 Turbo 186 Microline Okidata
Part #41364 Product DescriptionLIT,Manual Okidata 184 Turbo User ?

Models

Part #?90969 Product DescriptionPrinter,Okidata Microline 186 Serial with Standard Serial and USB interfaces 9-pin Printhead, 128K Memory Buffer, 115VAC replacement, uses same accessories as RLWS PN 20188
