Rice Lake RL32218S-HE Stainless Steel, Single-Ended Beam

$0.00

The RL32218S-HE model is similar to the RL32019S-HE but with 20 ft of PTFE cable. As with the RL32019S-HE, this model is also hermetically sealed and comes in capacities from 1,000 to 10,000 lb.

Download product PDF
Categories: ,

Specifications

Full Scale Output:
2.0 mV/V ?0.05% current matched

Output Resistance:
350 (? 3) ohm

Input Resistance:
400 (? 20) ohm

Material/Finish:
Stainless steel

Temperature:
Compensated range: 14? F to 104? F/-10? C to 40? C
Operating range: 0? F to 150? F/-18? C to 65? C



Seal Type:
Hermetically sealed, IP69K

Safe Overload:
150% full scale

Rated Excitation:
5-10 VDC (15 V maximum)

Combined Error:
0.017% full scale

Insulation Resistance:
>5,000 megohms

Cable Length:
20 ft (6.1 m) PTFE

Cable Color Code:
Red + Excitation
Black ? Excitation
Green + Signal
White ? Signal

Warranty:
Two-year limited warranty

Approvals:
cFMusus
NTEP

Models

191634 Load Cell,SEB RL32218S-HE 1000lb 20ft PTFE cable 2mv/v 350 Ohm NTEP III 5M FM WW IP69
191635 Load Cell,SEB RL32218S-HE 2500lb 20ft PTFE cable 2mv/v 350 Ohm NTEP III 5M FM WW IP69
191636 Load Cell,SEB RL32218S-HE 4000lb 20ft PTFE cable 2mv/v 350 Ohm NTEP III 5M FM WW IP69
191637 Load Cell,SEB RL32218S-HE 5000lb 20ft PTFE cable 2mv/v 350 Ohm NTEP III 5M FM WW IP69
191638 Load Cell,SEB RL32218S-HE 10000lb 20ft PTFE cable 2mv/v 350 Ohm NTEP III 5M FM WW IP69
