Specifications
Full Scale Output:
3.0 mV/V
Output Resistance:
349-355 ohm
Input Resistance:
343-357 ohm
Material/Finish:
Stainless steel
Temperature:
Operating range:
0? F to 150? F/-18? C to 65? C
Seal Type:
Environmentally sealed, IP67
Safe Overload:
150% full scale
Safe Sideload:
100% full scale
Rated Excitation:
5-10 VDC (15 V maximum)
Nonlinearity:
0.03% Full scale
Hysteresis:
0.02% Full scale
Insulation Resistance:
5,000 megohms
Deflection at Capacity:
250 lb-1,000 lb=0.013 in (0.33 mm)
2,000 lb-3,000 lb=0.015 in (0.38 mm)
4,000 lb-5,000 lb=0.025 in (0.64 mm)
10,000 lb=0.32 in (0.81 mm)
Cable Length:
20 ft (6.1m)
Cable Diameter:
0.200 polyurethane jacket
Cable Color Code:
Red…………………….+ Excitation
Black………………….? Excitation
Green …………………+ Signal
White ………………….? Signal
Warranty:
Two-year limited warranty
Approvals:
cFMus Approved
