Specifications
Print Speed:
2 in to 10 in per second
(51 mm to 152 mm)
Supply Roll Capacity:
8 in (203 mm) O D on 1.5 in to 3.0 in
(38 mm to 76.2 mm) cores.
Bar Code Modulus:
5 mil to 55 mil ?X? dimension in picket fence or ladder orientations
Media Width:
0.75 in to 4.65 in (17 mm to 118 mm)
Media Type:
Roll fed, die-cut or continuous labels;
perforated or continuous tag/ticket stock
Print Length:
0.25 in to 99 in (6 mm to 2475 mm)
Media Thickness:
0.0025 in to 0.0100 in (0.0635 mm to 0.254 mm)
Ribbons (Optional):
Industry standard ribbon widths:
1 in (25 mm) ribbon core, 1,476 ft (450 m) in length
Bar Codes:
Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5, code 128, EAN-8, EAN-13, HIBC, Codabar, Plessey, UPC 2 and 5-digit addendums, Code 93, Postnet, UCC/Ean Code 128, Telepen, UPS MaxiCode, FIM, PDF417, USD-8, Datamatrix, QR Code, Aztec, TLC 39, Micro PDF417, RSS
Graphics Support:
PCX, BMP and IMG files
Memory:
16 MB RAM (8 MB FLASH)
3 MB user available
Rating/Material:
IP69K/Stainless Steel 304
Interfaces:?
USB, Centronics Parallel port, RS-232 at 600 to 38,400 BPS
Power Source:?
Auto-sensing 103.5 to 126.50 or 207 to 253 VAC at 47 to 63 Hz; US or European power cord
Operating Temperature:
40? F to 95? F (4? C to 35? C)
Dimensions:
(H x W x L):27 x 14 x 13.6 in
(686.8 x 355.6 x 345.4 mm)
Approvals:
UL listed, CE marked
Processor:
Dragon ball, 150 MHz
Warranty:
One-year limited warranty
One-year or 1-million linear inches on original print head. 90 days on replacement print head
