RL1200 IS Intrinsically Safe Electromechanical Portable Beam Scale

$0.00

Download product PDF
Categories: ,

Features

Scale

  • NTEP Certified
  • 1,000 lb capacity
  • Conductive wheels to eliminate static buildup and discharge
  • Handle for ease of portability

Indicator

  • Intrinsically safe
  • LCD display with white LED backlight
  • Power ON/OFF; battery save mode

Specifications

Construction:
Cast-iron platform, base and leversPlatform Dimensions:
(L × W): 24 × 18 in		 Capacity:
1,000 lbApprovals:
NTEP 93-004 Class III 2,000d		 Warranty:
One-year limited
Power:
Input: 5.8 to 7.9 VDC, 100 to 175 mABattery (optional):
60 hours with 4 × 350 ohm load cells
80 to 100 hours with 1 × 350 ohm load cell
8 to 10 hour charging time

Annunciators:
Center of zero, gross, net, motion, lb, kg, oz, g

Display Increments:
1, 2, 5

 Display:
Seven-digit, seven-segment LCD display 121 × 24 dot
matrix messaging area with white LED backlightKeys/Buttons:
Flat membrane panel, tactile feel
882IS: zero, gross/net, tare, print, units conv, start, stop, on/off
882IS Plus: zero, gross/net, tare, print, units conv, start, stop, full numeric keypad, on/off		 Rating/Material:
IP66 enclosure
Stainless steelWarranty:
One-year limited

Approvals:
cULus Listed*
FM Entity
ATEX
IECEx
NTEP CC 19-015
Measurement Canada AM-6124C
OIML R76/2006-A-NL1-21.11
EU Test Certificate T11166
cULus* Listed
CE Marked
*cULus is only applicable to 882IS I/O and battery charger

Options

195558 Scale,RL1200IS Elect. Conversion 882IS Indicator with battery pack and charger, 1000 x .5lb, NTEP III
195560 Scale,RL1200IS Elect. Conversion 882IS Plus Indicator with battery pack and charger, 1000 x .5lb, NTEP III
