RL1600 Series Cast Iron Weigh Module

$0.00

Cast Iron Weigh Module

The RL1600 Series mounting module kit utilizes several Rice Lake Weighing Systems components to provide an unmatched level of performance in tank and hopper weighing applications. The RL1600 Series kit is ideally suited for indoor and outdoor process control operations in the medium- to high-capacity ranges. Each module incorporates self-checking capabilities for thermal expansion and contraction.

Applications:

  • Medium- to heavy-capacity tanks, bins and hoppers
  • Bulk material management
Download product PDF
Categories: ,

Features

Product PDF

RL1600 Series Cast Iron Weigh Module

Complete Kit Includes

  • Three or four RL1600 cast iron compression mounts with RL75016 environmentally protected double-ended shear beam load cells
  • One JB4SS NEMA Type 4X stainless steel signal trim junction box
  • 25 ft of hostile environment EL147HE SURVIVOR® load cell cable

Standard Features

  • Capacities (per module): 1,000 to 25,000 lb
  • Cast iron construction
  • Self-checking easy-to-use design allows module to be bolted directly to tank leg without requiring additional mounting plates or load buttons
  • Double-ended beam design, center loaded
  • Compatible with VPG® Sensortronics 65016 load cells, capacities (per module): 1,000 to 25,000 lb

Specifications

Rated Capacity C H H1 H2 L L1 L2 L3 T W W1 W2 W3 W2 W3
lb/in
1,000 to 5,000 0.56 5.00 0.50 0.50 9.31 2.75 4.00 6.25 1/2-13 UNC 5.00 3.75 2.75 4.00 3.00 6.00
10,000 to 25,000 0.78 7.89 0.75 0.75 12.00 6.00 8.00 7.50 3/4-10 UNC 8.00 6.00 6.00 8.00 5.12 8.00
