User configurable and custom designed to meet changing applications
Meets advanced Pharma compliance including user/password management for security, audit trail function logs and integrated alibi memory
RS-232 and USB communication
Easy cleaning by removing glass doors
Underweigh hook included
Manual glass draft shield
Choice of display
MCA – Large, high-end, 7″ color touchscreen TFT display in 16:9 format
MCE – State-of-the-art, TFT touchscreen operation
Specifications
225S
225P
125P
324S
224S
324P
124S
524S
524P
* MCE Large TFT Touchscreen and easy-to-use menu system
**MCA TFT color touchscreen, Ethernet and SD card reader
MCE*
Part #
195694
195797
195798
195695
195696
195801
195697
195799
195800
MCA**
Part #
195698
195802
195803
195700
195701
195805
195702
195699
195804
Capacity
220 g
60/120/220 g
60/120 g
320 g
220 g
80/160/320 g
120 g
520 g
120/240/520 g
Resolution
0.01 mg
0.01/0.02/0.05 mg
0.01/0.1 mg
0.1 mg
0.1 mg
0.1/0.2/0.5 mg
0.1 mg
0.1 mg
0.1/0.2/0.5 mg
Weighing Modes
Grams, Kilograms, Carat, Pounds, Ounces, Troy Ounce, Tael Hong Kong, Tael Singapore, Tael Taiwan, Grain, Pennyweight, Milligram, Parts per Pound, Tael China, Mommes, Austrian Carat, Tola, Baht, Mesghal, Ton, Pound:Ounces, Newton, Micrograms
Operating Modes
Mass Unit Conversion, SQ Min Function, ISO-Cal Function, Density Determination (Buoyancy method only with MSE), Calculation, Averaging, Formulation, Percent Weighing, Totalizing, Counting, Customized Identification, Statistics, Time Control Function, Second Tare Memory,
Over/Under Checkweighing
Repeatability
0.025 mg
0.015/0.04 mg
0.015/0.06 mg
0.1 mg
0.07 mg
0.1/0.2/0.4 mg
0.1 mg
0.1 mg
0.1/0.2/0.5 mg
Linearity
0.1 mg
0.15 mg
0.15 mg
0.3 mg
0.2 mg
0.5 mg
0.2 mg
0.4 mg
0.5 mg
Stabilization Time
2 seconds
2 seconds
2 seconds
1 seconds
1 seconds
1 seconds
1 seconds
1 seconds
1 seconds
Operating Temperature
41° F to 104° F (5° C to 40° C)
Weighing Chamber
(W x D x H) 8 x 8 x 10.2 in (205 x 205 x 261 mm)
Pan Size(W x D)
3.3 x 3.3 in (85 x 85 mm)
Dimensions
(W x D x H) 16 x 9.8 x 14.6 in (410 x 249 x 370.4 mm) (with manual draft shield)
Weight (Approx.)
18 lb
Est. Ship Weight
31.9 lb
29.7 lb
Calibration Weight
200 g
200 g
100 g
300 g
200 g
300 g
100 g
500 g
Power
120 V AC adapter auto ranging
Warranty
Two-year Limited Warranty
Return Policy
Sartorius Standard Policy – restock fee may apply
Options
Consult
DA: Automatic motorized draft shield for analytical balances (factory installed)
Consult
DI: Automatic motorized draft shield for analytical balances, with integrated ionizer (factory installed)
Consult
TR: Certificate of compliance and full factory test report (factory installed)
