SURVIVOR® AG Truck Scale

$0.00

Packs the performance of a SURVIVOR into a mid-size, mid-duty frame

Designed to provide reliable performance under the most demanding conditions, SURVIVOR scales are built with more structural steel, a superior support structure and innovative design features that provide consistent accuracy, less downtime and a longer scale life.

The AG livestock scale packs the performance of a SURVIVOR into a mid-size, mid-duty frame. The AG comes complete with a fabricated weighbridge for a concrete platform, load cells and mounts, as well as top access to load cells.

The AG is available with a standard concrete deck with a profile from 14 in to 16 in high, or with an optional steel deck. The AG is ideal for a variety of livestock and vehicle weighing applications.

Download product PDF
Category:

Features

  • 25,000 lb capacity load cells and pre-assembled G-force mounts
  • NTEP Certified
  • Up to 30,000 lb full scale capacity in 5 lb increments
  • Widths up to 15 ft
  • Lengths up to 43.75 ft
  • For concrete deck (rebar and pan not included)

Options

  • Steel deck
  • Fit existing foundations
  • Pit installations
  • Galvanized

Specifications

Load Cell Capacity:
25,000 lb

Concentrated Load Capacity:
20,000 lb

 Full Scale Capacity:
30,000 lb capacity (× 5lb)

Approvals:
NTEP Certified 98-008

 Warranty:
Weighbridge: Two-year limited
Parts: Two-year, including lightning protection

Options
