Tailor-made Load Pins $ 0.00
The Tailor-made Load Pins are designed for the measurement of tension or compression across a wide range of weighing applications. Mostly are made by high tensile stainless steel that suitable for applications in exposure of chemicals, dust, lightning or prolonged submersion in salt water. The load pins are offered from capacity ratings of 10kg to 1,000t, however, due to the nature of this type of product means that most load pins are manufactured to meet each customer’s needs and requirements.
View the standard specifications of these load pins to check if these will meet your needs and requirements or submit your order for a customized load pins.
To order a customized load pins, please submit your requirements by filling up the Load Pin Order Form at the LOAD PIN ORDER FORM tab.
Download product PDF
Specifications
Full Scale Output
1mV/V ± 10%
Zero Balance
± 0.02mV/V
Non-linearity
< ± 0.50%
Repeatability
< ± 0.30%
Hysteresis Error
< ± 0.50%
Creep in 30 minutes
< ± 0.20%
Input Resistance
400Ω ± 20Ω
Output Resistance
350Ω ± 3Ω
Recommended Excitation
10V (15V Maximum)
Insulation Resistance
> 2GΩ (50V DC)
Temperature Effect on Sensitivity
< ±0.020% of Cn/k
Temperature Effect on Zero Balance
< ± 0.020% of Cn/k
Compensated Temperature Range
– 10°C to 50°C/14°F to 122°F
Service Temperature Range
-30°C to 70°C/-20°F to 160°F
Storage Temperature Range
-50°C to 85°C/-58°F to 185°F
