VPG Celtron LOC Aluminum, Single Point Load Cell

$0.00

This product is being discontinued, limited quantities available.
Low-profile, off-center loading load cell. Designed for direct mounting of a weighing platform, hanging scales and other low-capacity beam applications.Long-term stability and durability are maintained. Capacities range from 5 kg to 100 kg (11.0 lb to 220.5 lb). Complete with 1 m (3.3 ft) and 3.1 m (10 ft) of load cell cable..

Download product PDF
Categories: ,

Specifications

Full Scale Output:
2.0 mV/V

Output Resistance:
350 (+/- 3) ohm

Input Resistance:
410 (+/- 10) ohm

Material/Finish:
Aluminum

Temperature:
Compensated range
14°F to 104°F (-10°C to 40°C)
Operating range
0° F to 150° F (-18° C to 65° C)

Seal Type:
Environmentally sealed, IP65

Safe Overload:
150% full scale

Rated Excitation:
5- 10 VDC (15 V maximum)

Combined Error:
0.25% full scale

Non-repeatability:
0.02%

Insulation Resistance:
5,000 megohms

Cable Length:
3 m (10 ft)

Cable Diameter:
0.200 PVC jacket

Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal

Max Platform Size:
16 in x 16 in (350 mm x 350 mm)

Warranty:
One-year limited warranty

Approvals:
cFMus
NTEP

Models

39810 Load Cell,SPT LOC-5kg 5kg 10FT Celtron 2mV/V 350 OHM WW Al NTEP III 5 S
39804 Load Cell,SPT LOC-50kg 50kg 10ft Celtron 2mV/V 350 OHM WW Al NTEP III 5 S
