Specifications
Full Scale Output:
3.0 mV/V
Output Resistance:
350 (± 3) ohm
Input Resistance:
385 (± 5) ohm
Material/Finish:
High-alloy steel, nickel plated
Temperature:
Operating range
0° F to 150° F (-18° C to 65° C)
Seal Type:
Environmentally sealed, IP65
Safe Overload:
150% full scale
Rated Excitation:
5- 10 VDC (15 V maximum)
Nonlinearity:
0.03% full scale
Hysteresis:
0.02% full scale
Insulation Resistance:
5,000 megohms
Cable Length:
5 ft (1.5 m)
Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal
Warranty:
One-year limited warranty
Approvals:
cFMus
