VPG Revere 5102 Alloy Steel, Single-Ended Beam Load Cell

$0.00

The model 5102 is a single-ended beam load cell. 500 lb (226.8 kg) capacities and above are constructed as shear beams. Its high accuracy, low profile and redundant sealing make it well suited for use in small and medium platform scales and process applications in harsh environments. Capacities range from 50 lb to 2,500 lb (22.7 kg to 1,134.0 kg). Complete with 10 ft (3.1 m) of load cell cable.

Download product PDF
Categories: ,

Models

21709 Load Cell,CLB 5102-D3-50- 10P1 50lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
21710 Load Cell,CLB 5102-D3-100 -10P1 100lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
21711 Load Cell,CLB 5102-D3-200 -10P1 200lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
21712 Load Cell,CLB 5102-D3-500 -10P1 500lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
21713 Load Cell,CLB 5102-D3-1K -10P1 1000lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
21714 Load Cell,CLB 5102-D3- 2.5K-10P1 2500lb 10ft 2mv/v 350 Ohm FM WW IP67 RTI
